A Distributed Magnetic Optimization Algorithm (MOA) Swarm Running on Numax

A distributed Magnetic Optimization Algorithm (MOA) swarm running on Numax. MOA (Tayarani-N. & Akbarzadeh-T., 2008) models candidate solutions as magnetic particles: each has a "mass" derived from how good its position is, and heavier particles pull lighter ones toward them, so the swarm converges on the strongest regions of the search space. Here the search space is a grid and "how good" a cell is comes from its magnetic pull toward a handful of weighted attractor points ("anchors") — the topology every particle ends up converging around.

Unlike distributed_ants (where the swarm only shares an anonymous pheromone field), every particle here knows about the others: it publishes its current position as an LWW-Register and reads every other particle's register before moving, so peer attraction is a real cross-node signal rather than something reconstructed after the fact.

Two things go beyond vanilla MOA, both real forces that feed the same movement decision, not separate modes:

LWW-Register used for live, per-participant state that every other node reads back (crdt_lww_set / crdt_lww_get) — a different replication shape than a single shared counter or field

PNCounter used two ways: as a live occupancy field (inc on entering a cell, dec on leaving), and as a live, externally-nudgeable weight adjustment per anchor — both read fresh every tick, so the guest's own movement logic reacts to values changed by an outside actor between ticks

GCounter used for a swarm-wide convergence stat (mag:settled_events)

local (non-replicated) per-node state via nx_sdk::db persisting across repeated nx run invocations of the same particle

nx_sdk::net::node_id, nx_sdk::crypto::random_bytes, nx_sdk::system::env_get combined into a stateful, randomized, configurable simulation, same building blocks as distributed_ants but composed into genuine inter-agent attraction/repulsion instead of trail-following

state that's entirely derived, never replicated: every particle's polarity is a pure function of its id, so every node computes every other particle's polarity locally with zero extra CRDT traffic

an emergent multi-node behavior that re-optimizes live: particles cluster around whichever anchor currently has the most mass, visibly migrate to a different anchor once a scripted weight change makes it the new best option, and pair up by opposite polarity along the way

Result

A real 14-particle run (16×16 grid, 3 anchors, 120 ticks/particle, seed = 7, polarity_enabled = true) runs a 6-phase scripted scenario: phase 1 is the plain seeded weights, then phases 2–6 each apply a live boost/cut to one or more anchors (see Configuration). The render shows, per phase, how many new particles crossed into settle_radius of an anchor since the previous phase — the heuristic in numbers: phase 2 (anchor 0 boosted to weight 19) adds +17 settles, phase 4 (anchor 2 boosted to 22) adds +16, phase 5 (anchor 0 re-boosted to 22) adds +6 — every boosted phase jumps well above the +2–+6 baseline drift of an unboosted phase.

render_topology.py turns one node's sequence of converged snapshots — one per phase — into a single HTML report that autoplays through every phase on a loop, no interaction needed: open it in a browser and watch the swarm re-cluster as each scripted weight change lands.

The same report auto-rotated to phase 5, right after anchor 0 is re-boosted to weight 22: every particle pair sharing a cell is an opposite-polarity (red/blue) pair, not two of the same, because same-polarity particles repel each other on top of the shared anchor pull:

The same scenario, same seed, run again with polarity_enabled = false (the Configuration toggle that restores the original, polarity-less MOA rule — every peer with more mass attracts, nothing ever repels) makes the effect obvious as a number, not just a visual impression: by the end of the run, mag:settled_events reaches ~80 with polarity on vs. ~197 with it off — without repulsion to spread same-polarity particles apart, far more of the swarm piles directly onto the winning anchor's exact cell instead of orbiting nearby, so it crosses the settle radius far more often. The same phase 5 snapshot with polarity disabled shows this directly: +35 new settles that phase (vs. +6 with polarity on) and up to 4 particles stacked on one cell instead of tidy opposite-polarity pairs:

cd examples/distributed_magnets cargo build --release --target wasm32-unknown-unknown

The module will be written to:

target/wasm32-unknown-unknown/release/distributed_magnets.wasm

How one tick works

nx run invokes a guest's run() exactly once per process, then exits — there's no in-guest loop or sleep. So "many simulation ticks" means re-invoking nx run repeatedly against the same --datastore-path, while --listen/--peer keeps that node's CRDT state synced with the others. Each invocation:

A related effect worth understanding rather than "fixing": because each anchor's pull is inverse-square in distance, a particle sitting exactly on a heavily-boosted anchor experiences a very steep local peak — its immediate neighbors are worth far less than the peak itself, but still far more than the pull of a more distant, even-heavier anchor. That local capture is realistic MOA/gradient-search behavior — it isn't a bug, and it's part of why watching the phases roll by is interesting: some particles snap onto a newly-favored anchor within a phase or two, others stay locked onto wherever they already were.

grid_width = 16 grid_height = 16 anchor_count = 3 seed = 7 # must be identical across every node in the swarm settle_radius = 1 ticks_per_particle = 120 particles = 14 base_port = 9100 polarity_enabled = true

phase_count = 6 phase2_at_tick = 21 phase2_boosts = "0:18" phase3_at_tick = 41 phase3_boosts = "0:-17,1:20" phase4_at_tick = 61 phase4_boosts = "1:-20,2:20" phase5_at_tick = 81 phase5_boosts = "2:-20,0:20" phase6_at_tick = 101 phase6_boosts = "0:-20,1:5,2:5"

Guest WASM has no filesystem access (only db/net/crdt/system/ crypto/time host calls), so this file is parsed host-side by demo.sh and re-exposed to every guest invocation as NUMAX_* env vars (plus a per-node NUMAX_PARTICLE_ID that demo.sh assigns). Changing grid_width/grid_height/anchor_count and re-running demo.sh changes the simulated search space accordingly — nothing is hardcoded in the guest.

phase_count counts phase 1 (the plain seeded weights), so phase_count = 6 means 5 scripted weight changes follow it; set it to 1 to disable the scenario entirely and run under fixed weights, like the very first version of this example did. For each phase N from 2 to phase_count, phaseN_at_tick is when node 0 (acting as the scenario controller) applies phaseN_boosts — a comma-separated list of anchor_index:delta pairs, applied as deltas on top of the anchor's current live weight (not target absolutes, since the underlying PNCounter only ever accumulates). Anchor indices are 0-based, in the order the seeded layout derives them — run demo.sh once and check the ANCHOR lines in logs/particle-0.log before tuning these for a different seed/grid. demo.sh validates that indices are in range and that tick numbers strictly increase before starting the swarm.

polarity_enabled toggles whether particles repel/attract by polarity at all (see With vs. without polarity); set it to false to fall back to the original MOA-only rule. demo.sh maps it to NUMAX_POLARITY=1/0 and rejects any value other than true/false.

Like distributed_ants, this is a many-node, many-tick simulation, so it's driven by a script instead of individual copy-pasted commands. From the repo root:

cargo build --release -p nx-cli cd examples/distributed_magnets cargo build --release --target wasm32-unknown-unknown ./demo.sh # uses swarm.config.toml ./demo.sh my-other-config.toml # or a different config file

This launches particles background nodes, fully meshed as peers, each looping ticks_per_particle times over its own datastore. On exit it prints each node's converged mag:settled_events GCounter (should agree across nodes, modulo a small skew from the timing of the final snapshot — that's normal eventual-consistency, not a bug) and points you at the log to render.

If you'd rather see a single raw tick by hand, the same underlying nx run invocation the script loops looks like:

NUMAX_GRID_W=16 NUMAX_GRID_H=16 NUMAX_ANCHOR_COUNT=3 NUMAX_SEED=7
NUMAX_SETTLE_RADIUS=1 NUMAX_PARTICLE_COUNT=14 NUMAX_PARTICLE_ID=0
../../target/release/nx run
target/wasm32-unknown-unknown/release/distributed_magnets.wasm
--listen 127.0.0.1:9600
--datastore-path ./data-single
--wait-before-run 100ms
--settle-for 300ms
--print-gcounter mag:settled_events

Re-running that same command against the same --datastore-path advances the same particle by one more step each time — local position state persists in nx_sdk::db between invocations. Add NUMAX_BOOST=0:18 to that command to apply a one-off boost the way the scripted scenario does.

python3 render_topology.py logs/particle-0.log --grid-width 16 --grid-height 16 --settle-radius 1 --out topology.html

Stdlib-only (no matplotlib/numpy, no external fonts or other network requests — the page is fully self-contained). It splits the log into one snapshot per SNAPSHOT,<label> marker (one per scripted phase, gated behind NUMAX_RENDER=1, which demo.sh sets automatically on the tick right before each boost lands, plus a final one at the end), parses each snapshot's FIELD,x,y,v / ANCHOR,x,y,weight / PARTICLE,id,x,y,mass lines, and writes a single HTML report where every phase is stacked in the same spot and a pure-CSS @keyframes animation autoplays through them in order, on an infinite loop — no JavaScript, no click-through needed. Each phase also reports how many new particles settled since the previous phase, so the effect of that phase's weight change is a number, not just a visual impression.

Particles sharing a cell are drawn as separate small dots arranged in a tight ring rather than one bigger dot, so a cluster of particles reads as a cluster, not as a single ambiguous blob; each dot is colored by that particle's polarity (red = positive, blue = negative — computed from particle_id % 2, the same rule the guest uses, so the colors always match what actually drove the simulation).

Open the resulting topology.html in a browser and let it run.

rm -rf examples/distributed_magnets/data-* examples/distributed_magnets/logs

Notes

Sync requires --listen <addr>; without it, crdt::* calls return SyncDisabled, matching every other example in this repo.

--wait-before-run / --settle-for follow the same convention as the other examples — see distributed_counter's README for a fuller explanation of both.

Reusing datastores between demo.sh runs of the same config is fine; changing grid size, anchor count, or particle count mid-simulation isn't (positions and particle ids from a smaller/differently-seeded world may fall outside the new grid or collide), so demo.sh always clears data-*/logs first.

The scripted controller boosts are only ever applied by particle 0's own tick loop; every other particle only ever reads live anchor weights, never writes them, so there's no risk of two nodes double-applying the same scripted delta.

Future direction: driving weights from a real external signal

(Design notes only — nothing below is implemented in this crate.)

demo.sh's phase schedule is a fixed script known in advance. A natural extension: drive mag:anchor_boost:{index} from something outside the swarm entirely — a monitoring pipeline, a human operator's live input, or another Numax module reacting to real conditions — instead of a pre-written tick schedule. Because the guest already reads every anchor's effective weight fresh each tick with no other assumption about why it changed, no change to the movement logic would be needed at all; only the source of the pncounter::inc/dec calls would move from demo.sh to whatever real signal should be steering the topol
